Leakproof Pump

Flow Rate: 6~90m³/h
Head range: 8~22 m
Caliber: DN40~DN100
Motor power: 0.75~7.2kW
Speed range: 2900 r/min
Ambient temperature:≤40℃
Insulation Class: F+
IP Rating: IP55+

Send Inquiry

Features

Base Configuration

➣ 2-pole IE3 Motor

➣Cast Iron Pump Body

➣E-coated & Cast Iron Impeller

➣Stainless Steel Shaft

➣Back-to-back (Double) Seal

Product description

The SD series Leakproof pump features a special single-stage, single-suction design and is specially developed for the surface treatment industry, including UV coating, water-based paint spraying, exhaust scrubber dust removal, and the coating industry.

In these applications, the extracted liquid often mixes with paint residue or treatment solution, which can harden and build up on the mechanical seal surface. This may prevent the rotating and stationary seal faces from sealing properly, resulting in leakage.

Its key features include a dual-chamber concealed sealing design that helps prevent damage to the mechanical seal, allowing the pump to operate reliably even under harsh working conditions. It also offers long service life, leak-free performance, a compact installation footprint, small overall size, and easy maintenance.

Features

Dual-Chamber Architecture

The SD Leakproof pump features a dedicated cooling chamber and oil chamber to prevent media scaling on mechanical seal mating surfaces, effectively eliminating leakage or clogging caused by sediment buildup.

High Performance

The SD Leakproof Pump features IE3 motos as default for high energy efficiency, as well as ultra-low noise operation.

Advanced Design

The SD Leakproof Pump also use our self-developed one-piece molded terminal box, motor housing and fan cover, as well as the integrated motor-pump structure.

Active Thermal Regulation

The pump facilitates liquid circulation through the cooling chamber to lower oil temperature, providing continuous cooling for the mechanical seal to ensure optimal performance.

Applications and Precautions

Main application: spraying equipment water circulation, glass industry
deep processing water circulation supply, automotive cleaning industry,
hot water scale project, water curtain cabinet, coating industry, hard water delivery

Precautions：

• To prevent electric shock, always disconnect the power supply before servicing or cleaning the pump.

• To reduce the risk of electric shock, the pump must be properly grounded.

• Please install overload and leakage protection devices before starting the pump.

Qualification Certificate

Sales And Service Network

product-1-1

FAQ

Q: What is a leakproof pump designed for?

A: A leakproof pump is built to prevent liquid from escaping during operation. It is commonly used in applications where even a small leak could cause safety issues, contamination, or product loss.

Q: How does a leakproof pump avoid leakage?

A: It typically uses special sealing methods or a seal-less design, depending on the type. Some models rely on magnetic drive systems, while others use advanced sealing structures to keep the liquid fully contained inside the pump.

Q: What kind of fluids are usually handled by leakproof pump?

A: They are often used for chemicals, hazardous liquids, volatile fluids, or any medium that should not come into contact with the outside environment. The exact compatibility depends on the pump materials and design.
